TCL 43P715 User Manual

10
Chapter 3 Basic TV Operations
Accessing Channels
-
Using the RC802N Remote Control
Using the numeric buttons
: press the corresponding
numeric buttons on the remote control to access the
channels.
Using the P / buttons
: press the
P /
buttons
on the remote control to scroll through the channels.
Using the LIST button
: press the
LIST
button to
display the channel list and press
▲/▼/◄/►
and
OK
to
select channels.
-
Using the RC802V Remote Control
Using the
▲/▼
buttons
: press the ▲/▼ buttons on the
remote control to scroll through the channels.
Using the OK button
: press the
OK
button to display
the channel list and press
▲/▼/◄/►
and
OK
to select
channels.
Using the P / buttons
: press the
P /
buttons on
the remote control to scroll through the channels.
Using the button
: press to display the virtual
remote control keyboard, then you can use the numeric
buttons or the
LIST
button to operate accordingly.
Watching Connected Devices
Press on the remote control to display the source
list. Press
▲/▼
to select
TV
or other input sources and
press
OK
toconrm.
You can also press on the remote control to display
the homepage, press
▲/◄/►
to move the cursor to
the
(Inputs)
area on the right top of the screen, and
press
OK
to enter. Then press
▲/▼
and
OK
to select
the input source.
Adjusting Volume
Volume control
: press the
/
buttons on the
remote control or the corresponding buttons on the TV
set to increase or decrease the volume.
Sound mute
: press the button to temporarily mute
the sound. Press this button again or the button to
restore the sound.
(Available for RC802N remote control
only.)
Accessing Smart TV Homepage
Allows you to enjoy Internet Applications (Apps) and
specially adapted Internet websites, and perform system
settings for your TV. You can make controlling with the
TV remote control.
WARNING:
• Congurethenetworksettingsbeforeusing
Smart TV
applications
.
• Slow responses and/or interruptions may occur,
depending on your network conditions.
• If you experience a problem using an application,
please contact the content provider.
• According to circumstances of the content provider, an
application’s updates or the application itself may be
discontinued.
• Depending on your country's regulations, some
applications may have limited service or not be
supported.
• Changes in application content may be made without
prior notice by the service provider.
1.
Press on the remote control to display the Smart
TV homepage.
2.
Press
▲/▼/◄/►
and
OK
to enter the desired apps,
functions or settings.
3.
Press to return to the homepage.
4.
To exit the homepage, press
▲/◄/►
to move the
cursor to the
(Inputs)
area on the right top of the
screen, press
OK
to enter and then press
▲/▼
and
OK
to select your desired input source.
Note:
since the connection with Internet takes time, it’s
recommended that you wait a few minutes to use the
Smart TV feature after activation of TV from standby.
Accessing Google Play
Google Play is your entertainment unbound. It brings
together all of the entertainment you love and helps
you explore it in new ways, anytime, anywhere. We’ve
brought the magic of Google to music, movies, TV,
books, magazines, apps and games, so you get more
from your content every day.

TCL 43P715 Specifications

General

Screen shape	Flat
Response time	10 ms
Display diagonal	43 \
Display brightness	270 cd/m²
Display technology	LCD
Native aspect ratio	-
Native refresh rate	60 Hz
Peak luminance ratio	74 %
LED backlighting type	Direct-LED
Viewable size diagonal	1080 mm
Display diagonal (metric)	109.2 cm
Motion interpolation technology	PPI (Picture Performance Index) 1500
Dynamic contrast ratio marketing name	Mega Contrast
Tuner type	Analog & digital
Auto channel search	Yes
Analog signal format system	NTSC, PAL, SECAM
Digital signal format system	DVB-C, DVB-S2, DVB-T2
Video apps	Amazon Prime Video, Netflix, YouTube
Smart modes	Game, Movie, Sports
Operating system version	9.0
Operating system installed	Android
Hybrid Broadcast Broadband TV (HbbTV) version	2
Audio decoders	Dolby Digital, Dolby Digital AC4
RMS rated power	20 W
Wi-Fi standards	802.11b, 802.11g, Wi-Fi 4 (802.11n)
Bluetooth profiles	A2DP, HID
Product color	Silver
Mercury content	0 mg
Panel mounting interface	200 x 200 mm
Processor cores	4
Audio formats supported	MP3, WMA
Image formats supported	BMP, HEIF, JPG, PNG
Video formats supported	AVI, H.264, H.265, MKV, MP4, MPG, TS, VP9, WEBM, WMV
Picture processing technology	TCL IPQ 2.0 Engine
High Dynamic Range (HDR) technology	High Dynamic Range 10 (HDR10), Hybrid Log-Gamma (HLG)
RF connector type	F, IEC
HDMI ports quantity	3
USB 2.0 ports quantity	USB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
Ethernet LAN (RJ-45) ports	1
Consumer Electronics Control (CEC)	T-link
Common interface Plus (CI+) version	1.4
Number of OSD languages	29
Firmware upgradeable via	Network, USB
On Screen Display (OSD) languages	ALB, BUL, CRO, CZE, DAN, DEU, DUT, ENG, ESP, EST, FIN, FRE, GRE, HUN, ITA, LAV, LIT, MAC, NOR, POL, POR, RUM, RUS, SER, SLK, SLV, SWA, TUR, UKR
AC input voltage	220 - 240 V
AC input frequency	50 Hz
Energy efficiency scale	A to G
Power consumption (max)	90 W
Power consumption (standby)	0.29 W
Power consumption (typical)	54 W
Remote control type	RC802N4
Package depth	133 mm
Package width	1145 mm
Package height	665 mm
Package weight	9100 g
Battery type	AAA
Battery weight	15 g
Battery technology	Alkaline
Truck type	87 cbm
Pallet width	1200 mm
Pallet height	1442 mm
Pallet length	800 mm
Pallet weight	133700 g
Pallet net weight	12500 g
Quantity per truck	396 pc(s)
Quantity per pallet	12 pc(s)
Number of pallets per truck	33 pc(s)
Maximum number of stacking cartons	4 pc(s)

Weight and Dimensions

Depth (with stand)	301 mm
Height (with stand)	613 mm
Weight (with stand)	6900 g
Depth (without stand)	78 mm
Width (without stand)	958 mm
Height (without stand)	566 mm
Weight (without stand)	6700 g
