Page #13 background imageLoading...
Page #13 background image
13
Using more of your TV
4. Networked
standby
is set to
On
in the
Network
menu under homepage by pressing
>
(Settings)
>
Network & Internet
and use
to select
Networked
standby
and press
OK
to
activate.
When the TV is in networked standby mode, you can
use the app to wake up the TV remotely.
Notes:
- This feature is disabled if you press and hold the
button on the remote control and conrm to
shut the TV down
- Before using the feature of network wake up, make
sure
(Settings)
>
Device Preferences
>
Power
>
Instant power on
is set to on.
T-Link
Use this function to search for CEC devices connected
to the HDMI sockets in your TV and enable auto power
on and auto standby between the TV and CEC devices.
Enabling or Disabling T-Link
1.
Press
on the remote control, select
System >
T-Link
and press
OK/►
to enter.
2.
Press
/
to select
T-Link
and press
OK/►
to
enter.
3.
Press
/
to select
On
or
Off
and press
OK
to
conrm.
4.
Press
EXIT
or
to close the menu.
Using Auto Power On
Enables the TV to automatically power on when you
power on a CEC device (e.g. DVD) with the device’s
remote. Select
On
to enable this function.
Using Auto Standby
Enables all CEC devices to automatically go to the
standby mode when you turn off the TV with the TV
remote. Select
On
to enable this function.
Note:
the CEC functions depend on the devices
connected and it is possible that some devices may not
interoperate correctly when connected to this TV. The
user manual or the manufacturer of the problematic
devices should be consulted for further information.
T-Cast
T-Cast lets you enjoy plenty of videos, rich of
applications, and share great contents on large screen.
It also allows you to turn a smart device into a sophisti-
cated remote control, providing more features than your
normal TV remote control. You can then control your TV
through your smart device.
Follow the on-screen instructions to scan the QR code
on the TV screen and download T-Cast.
Note: Make sure the smart device and your TV are
in the same home LAN (local area network) or
network segment to use TV remote function.
Using EPG
(Electronic Programme Guide)
EPG is an on-screen guide that displays scheduled
digital TV programmes. You can navigate, select and
view programmes.
Note
: the DTV EPG does not require an internet
connection.To use the DTV EPG, HbbTV must be set
to
Off
. when HbbTV is set to
ON
,
then it will enter the
HbbTV EPG directly. Please refer to “
HbbTV
” part of
this manual for assistance to set HbbTV to on or off.
1.
Press
on the remote control, select
Channel >
EPG
and press
OK/
to enter, or press
GUIDE
directly
(if available)
on the remote control, the
Programme Guide
menu will appear, which allows
you to get information about the current or next
programme playing on each channel. Navigate
through the different programmes using the
▲/▼/◄/►buttonsontheremotecontrol.
2.
Use the related buttons shown at the bottom of the
screen to view EPG.
- Programme lter
:Programmeguidelterfor
digital TV programmes.
• Press to display the type list of the
programme.
• Navigate through the different types using the
▲/▼buttonsontheremotecontrol.
• Select one or more types, which you want to
highlight from the type list, press
OK
to select or
deselect. A checkmark will appear to the right of
the type when selected.
- Custom schedule
:Press▲/▼toselecta
programme, then press the
RED
button to set
the schedule, press
OK
toenteranduse▲/▼
to select
Schedule reminder
or
Schedule
recording
.
- Select date
: Press the
GREEN
button to select
date.
- Schedule list
: Press the
YELLOW
button to view
your schedule list.
Note:
if using the remote control of RC802V, to access
the colour buttons, you need to press button on
the remote control to display the
virtual remote control
keyboard rst.
3.
Press to exit EPG.
Bluetooth Function
(* not available for some models)
Bluetooth
®
is a wireless technology standard for
exchanging data over short distance between Bluetooth
devices. You can connect Bluetooth audio device,

Questions and Answers:

Question and Answer IconNeed help?

Do you have a question about the TCL 43P715 and is the answer not in the manual?

TCL 43P715 Specifications

General IconGeneral
Screen shapeFlat
Response time10 ms
Display diagonal43 \
Display brightness270 cd/m²
Display technologyLCD
Native aspect ratio-
Native refresh rate60 Hz
Peak luminance ratio74 %
LED backlighting typeDirect-LED
Viewable size diagonal1080 mm
Display diagonal (metric)109.2 cm
Motion interpolation technologyPPI (Picture Performance Index) 1500
Dynamic contrast ratio marketing nameMega Contrast
Tuner typeAnalog & digital
Auto channel searchYes
Analog signal format systemNTSC, PAL, SECAM
Digital signal format systemDVB-C, DVB-S2, DVB-T2
Video appsAmazon Prime Video, Netflix, YouTube
Smart modesGame, Movie, Sports
Operating system version9.0
Operating system installedAndroid
Hybrid Broadcast Broadband TV (HbbTV) version2
Audio decodersDolby Digital, Dolby Digital AC4
RMS rated power20 W
Wi-Fi standards802.11b, 802.11g, Wi-Fi 4 (802.11n)
Bluetooth profilesA2DP, HID
Product colorSilver
Mercury content0 mg
Panel mounting interface200 x 200 mm
Processor cores4
Audio formats supportedMP3, WMA
Image formats supportedBMP, HEIF, JPG, PNG
Video formats supportedAVI, H.264, H.265, MKV, MP4, MPG, TS, VP9, WEBM, WMV
Picture processing technologyTCL IPQ 2.0 Engine
High Dynamic Range (HDR) technologyHigh Dynamic Range 10 (HDR10), Hybrid Log-Gamma (HLG)
RF connector typeF, IEC
HDMI ports quantity3
USB 2.0 ports quantityUSB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
Ethernet LAN (RJ-45) ports1
Consumer Electronics Control (CEC)T-link
Common interface Plus (CI+) version1.4
Number of OSD languages29
Firmware upgradeable viaNetwork, USB
On Screen Display (OSD) languagesALB, BUL, CRO, CZE, DAN, DEU, DUT, ENG, ESP, EST, FIN, FRE, GRE, HUN, ITA, LAV, LIT, MAC, NOR, POL, POR, RUM, RUS, SER, SLK, SLV, SWA, TUR, UKR
AC input voltage220 - 240 V
AC input frequency50 Hz
Energy efficiency scaleA to G
Power consumption (max)90 W
Power consumption (standby)0.29 W
Power consumption (typical)54 W
Remote control typeRC802N4
Package depth133 mm
Package width1145 mm
Package height665 mm
Package weight9100 g
Battery typeAAA
Battery weight15 g
Battery technologyAlkaline
Truck type87 cbm
Pallet width1200 mm
Pallet height1442 mm
Pallet length800 mm
Pallet weight133700 g
Pallet net weight12500 g
Quantity per truck396 pc(s)
Quantity per pallet12 pc(s)
Number of pallets per truck33 pc(s)
Maximum number of stacking cartons4 pc(s)
Weight and Dimensions IconWeight and Dimensions
Depth (with stand)301 mm
Height (with stand)613 mm
Weight (with stand)6900 g
Depth (without stand)78 mm
Width (without stand)958 mm
Height (without stand)566 mm
Weight (without stand)6700 g
