14
4. Say "Ok Google" or "Hey Google" to activate it.
Notes:
- The availability of hands-free TV voice control
depends on your region/country/language and your
model. For details, please refer to your local dealer.
- A quiet surrounding is required for better function
when using it. The recommended distance for using
the hands-free TV voice control is within 2 meters in
front of TV set.
- Turn the built-in MIC switch to off if you are not going
to use it. Or set
(Settings) > Device Preferences
> Google Assistant > On to off.
- Standby power consumption will increase because
the built-in MIC is always listening when the Google
Assistant or voice control with the built-in MIC is
enabled.
- It is recommended to set
(Settings) > Device
Preferences > Google Assistant > On to off to
avoid interference when there are two or more
terminals using the Google Assistant function at the
same time.
Multi Visual
Allows you to enjoy different programmes with your
family on one TV at the same time.
The multi visual function is enabled by default. To use
the function, make sure your phone is Android OS and
the WiFi on the phone is turned on. Then follow the
steps below to operate.
1. Press
on the remote control, select (Settings)
> Network & Internet > Wi-Fi, and press OK to turn
it on.
2. Activate the cast screen function on your phone and
choose the TV’s name you want to connect in the
searching list.
3. For the rst time, depending on different types of
phones, there are two situations: 1) an invitation
prompt appears, select "Accept" and press OK to
connect. 2) enter a correct PIN code to connect as
per the PIN message on the phone.
4. Then dual views display and you can enjoy different
programmes at the same time.
5. If you want to watch only one programme, use ◄/►
to select your desired view and press OK to enter
the full screen.
6. To return to the previous dual view screen, press and
hold
on the remote control.
7. To exit the multi visual function, press
to display a
dialog box, then select OK and press OK to conrm.
Notes:
- This feature is not available in any of the cases
below:
a) when TV is in Netfilx or Media Player.
b) if the video from phone/DTV is scrambled.
c) when the capacity of required video decoding
exceeds 4K 60Hz.
- When in full screen mode, due to the compatibility
of the third party's Apps, there might occur failure to
return to the dual views.
- At most 2 phones can be cast to the TV at the same
time. When in dual view mode, use ◄/► to move
the focus to TV view and then cast another phone to
the TV.
- To disable the feature, select
(Settings) > Device
Preferences > Multi visual settings > Multi visual
and press OK to turn it off.
- To check all available history list, select
(Settings)
> Device Preferences > Multi visual settings >
Connection list and press OK to enter.

Table of Contents

Questions and Answers:

Question and Answer IconNeed help?

Do you have a question about the TCL 65C728 and is the answer not in the manual?

TCL 65C728 Specifications

General IconGeneral
Screen shapeFlat
Response time- ms
Display diagonal65 \
Display brightness- cd/m²
Display technologyQLED
Native aspect ratio16:9
Peak luminance ratio65 %
Display diagonal (metric)164 cm
Motion interpolation technology-
Dynamic contrast ratio marketing nameMega Contrast
AC input voltage220 - 240 V
AC input frequency50 Hz
Energy efficiency scaleA to G
Power consumption (standby)0.5 W
EqualizerYes
Sound modesMovie, Sports
Audio decodersDolby Atmos, Dolby Digital, Dolby Digital AC4, Dolby TrueHD
RMS rated power20 W
Number of speakers2
Product colorBlack
Mercury content0 mg
Panel mounting interface300 x 300 mm
Package depth165 mm
Package width1645 mm
Package height1000 mm
Package weight26800 g
Processor cores4
High Dynamic Range (HDR) technologyDolby Vision IQ, High Dynamic Range 10 (HDR10), High Dynamic Range 10+ (HDR10 Plus), Hybrid Log-Gamma (HLG)
USB 2.0 ports quantityUSB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
Ethernet LAN (RJ-45) ports1
Consumer Electronics Control (CEC)T-link
Common interface Plus (CI+) version1.4
Tuner typeAnalog & digital
Analog signal format systemNTSC, PAL, SECAM
Digital signal format systemDVB-C, DVB-S2, DVB-T2
Video appsAmazon Prime Video, Netflix, YouTube
Operating system version11.0
Operating system installedAndroid
Hybrid Broadcast Broadband TV (HbbTV) version2.0.2
Wi-Fi standards802.11b, 802.11g, Wi-Fi 4 (802.11n)
Bluetooth profilesA2DP, HID
Repairability index6.5
Weight and Dimensions IconWeight and Dimensions
Depth (with stand)300 mm
Width (with stand)1466 mm
Height (with stand)888 mm
Weight (with stand)19500 g
Depth (without stand)83 mm
Width (without stand)1446 mm
Height (without stand)827 mm
Weight (without stand)19200 g
