13
Using More of Your TV
user manual or the manufacturer of the problematic
devices should be consulted for further information.
Password in Parental Controls
-
Set the password in the
(Settings)
> System >
Parental Controls
menu.
-
The super password is 0423. If you forget your code,
enter the super password to override any existing
codes.
Using Quick Start Function
It enables you to turn on your TV faster from standby
mode than turning this function o󰀨, but it will also
increase standby power consumption.
1.
Press
on the remote control, select
(Settings)
> System > Power and energy > Quick start
and
press
OK/Right
to enter.
2.
Select the
Quick start
option and press
OK
to
toggle between on and o󰀨.
3.
Press
to return to the previous menu.
Bluetooth Function
(* not available for some models)
Bluetooth
®
is a wireless technology standard for
exchanging data over short distance between Bluetooth
devices. You can connect Bluetooth audio device,
mouse or keyboard via the TV.
1.
Press
on the remote control
, select (Settings)
>
Remotes & Accessories and press OK to enter.
2.
Select
Pair accessory
and press
OK
to enter.
The TV will search nearby Bluetooth devices
automatically.
3.
Select an available device, press
OK
and follow the
guides on the screen to connect it.
Note:
Bluetooth technology (if available in your TV)
uses 2.4GHz frequency thus close proximity to Wi-
Fi access points, routers or microwave ovens might
interfere with Bluetooth audio streaming. If you face
interruptions in audio reception, you should restart
your Bluetooth device to nd frequency with less
interferences and if you continue to face issues you
should move closer to TV or increase space between
TV and source of interferences.
The Bluetooth
®
word mark and logos are registered
trademarks owned by Bluetooth SIG, Inc. and any use
of such marks by TTE Corporation is under license.
Other trademarks and trade names are those of their
respective owners.
Blue Light Filter
It reduces the amount of blue light emitted by the
screen, which can reduce the visual fatigue associated
with screen viewing.
1.
Press
on the remote control to display the
dashboard, select
>
Advanced Settings
>
Color
and press
OK/Right
to enter.
2.
Select the
Blue Light Filter
option,
and press
OK
to
toggle between on or o󰀨.
Notes:
-
After watching TV for half an hour, please move
away from the TV and rest your eyes.
-
When resting, please look far away to adjust the
ciliary muscles of the eye to avoid eye strain.
-
Please form a good habit of doing eye exercises
to protect eyesight and prevent myopia.
Reset Shop
Allows you to reset the TV to factory default settings.
1.
Press
on the remote control, select
(Settings) >
System > About > Reset
and press
OK
to enter.
2.
Press
Up/Down
to select
Factory Reset
and press
OK
to enter. Then select
Erase Everything
and
press
OK
to conrm.
3.
Enter the password you have set or the PIN
according to the on-screen prompt.
4.
Select
OK
and press
OK
to confirm.
5.
The
Initial setup
wizard appears. Follow the
instructions in the section
Initial setup
.
Multi Visual
Allows you to enjoy di󰀨erent programs with your family on
one TV at the same time.
The multi visual function is enabled by default. To use
the function, make sure your phone is Android OS and
the WiFi on the phone is turned on. Then follow the steps
below to operate.
1.
Press
on the remote control, select
(Settings) >
Network & Internet >
Wi-Fi
,
and press
OK
to turn it
on.
2.
To enter the feature, press
on the remote
control,then select
Multi Visual >
Select your desired
display mode and press
OK
to enter.
Press
"Start
now"
to connect.
3.
Activate
the cast screen function on your phone and
choose the TV’s name you want to connect in the
searching list.
