Page #12 background image
EN
12
English
Using more of your TV
Selecting a subtitle type on digital TV
channels
1.
Press
on the remote control, select
Settings >
Channels and inputs > Channels > Subtitle >
Subtitle type
and press
OK/
to enter.
2.
Press
/
to select a subtitle type and press
OK
to conrm. You can select
Hearing impaired
to display the hearing impaired subtitles with your
selected language.
3.
Press to return to the previous menu.
Using Teletext
Selecting decoding page language
1.
Press
on the remote control, select
Settings >
Channels and inputs > Channels > Teletext >
Decoding page language
and press
OK/
to
enter.
2.
Press
/
to select a proper type of language
in which Teletext will display and press
OK
to
conrm.
3.
Press to return to the previous menu.
Digital Teletext language
On digital TV channels, depending on the
broadcaster, you may be able to enjoy a service with
multiple initial Teletext pages in di󰀨erent languages.
This function allows you to select an available
language as primary language, which relates to
di󰀨erent initial Teletext pages.
1.
Press
on the remote control, select
Settings >
Channels and inputs > Channels > Teletext >
Digital teletext language
and press
OK/
to
enter.
2.
Press
/
to select a language and press
OK
to conrm.
3.
Press to return to the previous menu.
External devices control (CEC)
Use this function to search for CEC devices connected
to the HDMI sockets in your TV and enable one-touch
play and one-touch standby between CEC devices.
Enabling or disabling CEC
1.
Press
on the remote control, select
Settings
> Channels and inputs > External Inputs >
External devices control (CEC)
and press
OK/
to enter.
1.
Select the
HDMI Control
option, and press
OK
to
toggle between on or o󰀨.
2.
Press to return to the previous menu.
Power on the TV in sync
Enables the TV to automatically power on when you
power on a CEC device (e.g. DVD) with the device’s
remote. Press
OK
to turn it on to enable this function.
Device standby in sync
Enables all CEC devices to automatically go to the
standby mode when you turn o󰀨 the TV with the TV
remote. Press
OK
to turn it on to enable this function.
Note: The CEC functions depend on the devices
connected and it is possible that some
devices may not interoperate correctly when
connected to this TV. The user manual or
the manufacturer of the problematic devices
should be consulted for further information.
HbbTV
HbbTV (Hybrid broadcast broadband TV) is a service
o󰀨ered by certain broadcasters and available only on
some digital TV channels. HbbTV delivers interactive
television over broadband Internet. These interactive
features are added to and enrich the normal digital
programmes, and include services such as digital
teletext, electronic programme guide, games, voting,
specic information related to the current programme,
interactive advertising, information magazines, catch-
up TV, etc.
To use HbbTV please ensure your TV is connected to
Internet and HbbTV is switched on.
Notes:
-
HbbTV services are broadcast- or country-
dependent and may be unavailable in your area.
-
You cannot download les to your TV with
HbbTV function.
-
Application provider or broadcasting related
conditions may cause an HbbTV application to
be unavailable momentarily.
-
To access HbbTV applications you must connect
your TV to the Internet via a broadband link.
HbbTV applications may not work correctly in
case of network related issues.
HbbTV access
1.
Press
on the remote control, select
Settings >
System > HbbTV settings
and press
OK/
Select
the
HbbTV
option, and press
OK
to turn it on.
2.
When you tune to a digital TV channel that o󰀨ers
HbbTV, this will be signalled to you by an on-
screen indication (generally a red button, but
other colour buttons may also be used). Press
the indicated colour button to open the interactive
pages.
3.
Use
/ / /
and the colour buttons to
navigate through the HbbTV pages and press
OK
to conrm.

Questions and Answers:

Question and Answer IconNeed help?

Do you have a question about the TCL 75P755 and is the answer not in the manual?

TCL 75P755 Specifications

General IconGeneral
Screen shapeFlat
LED backlightYes
Response time15 ms
Display diagonal75 \
Display brightness- cd/m²
Display technologyLED
Native aspect ratio16:9
Native refresh rate60 Hz
Peak luminance ratio65 %
LED backlighting typeDirect-LED
Contrast ratio (typical)-
Display diagonal (metric)189.3 cm
Display refresh rates supported120 Hz
Motion interpolation technologyPPI (Picture Perfomance Index) 2800
Dynamic contrast ratio marketing nameMega Contrast
Audio decodersDTS Virtual:X, DTS-HD, Dolby Atmos, Dolby Audio, Dolby TrueHD
RMS rated power30 W
Built-in subwooferNo
Number of speakers2
Audio output channels2.0 channels
Stand typeLegs stand
Product colorTitanium
Panel mounting interface400 x 400 mm
AC input voltage220 - 240 V
AC input frequency50 Hz
Energy efficiency scaleA to G
Power consumption (standby)0.5 W
Power consumption (typical)245 W
Package depth178 mm
Package width1850 mm
Package height1125 mm
Package weight33600 g
Game featuresAuto Low Latency Mode (ALLM), Game Master 3.0
Processor cores4
Audio formats supportedMP3, WMA
Image formats supportedBMP, HEIF, JPG, PNG
Video formats supportedAVI, MKV, MP4, MPG, TS, VP9, WEBM, WMV
Video compression formatsAV1, H.264, H.265, VP9
Picture processing technologyTCL AiPQ Engine
High Dynamic Range (HDR) technologyDolby Vision, High Dynamic Range 10 (HDR10), High Dynamic Range 10+ (HDR10 Plus), Hybrid Log-Gamma (HLG)
HDCP version2.2
Headphone outputs0
RF connector typeF, IEC
HDMI ports quantity3
USB 2.0 ports quantityUSB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
Ethernet LAN (RJ-45) ports1
Consumer Electronics Control (CEC)T-link
Common interface Plus (CI+) version1.4
Tuner typeAnalog & digital
Analog signal format systemNTSC, PAL BG, PAL DK, PAL I, PAL L, SECAM B/G, SECAM D/K, SECAM L
Digital signal format systemDVB-C, DVB-S2, DVB-T2
Video appsAmazon Prime Video, Apple TV, Netflix, YouTube
Smart modesSports
Operating system versionATV 12.0
App distribution platformGoogle Play
Operating system installedGoogle TV
Hybrid Broadcast Broadband TV (HbbTV) version2.0.2
Programming period8 day(s)
Number of OSD languages29
Firmware upgradeable viaNetwork, USB
On Screen Display (OSD) languagesALB, BUL, CRO, CZE, DAN, DEU, DUT, ENG, ESP, EST, FIN, FRE, GRE, HUN, ITA, LAT, LIT, MAC, NOR, POL, POR, RUM, RUS, SER, SLK, SLV, SWE, TUR, UKR
Wi-Fi standards802.11b, 802.11g, Wi-Fi 4 (802.11n)
Bluetooth version5.0
Bluetooth profilesA2DP, HID, SBC
Sustainability certificatesTÜV mark
Remote control typeRC833
Doesn't containCadmium
Warranty period2 year(s)
Weight and Dimensions IconWeight and Dimensions
Stand width1288 mm
Depth (with stand)351 mm
Width (with stand)1667 mm
Height (with stand)1025 mm
Weight (with stand)23600 g
Depth (without stand)71 mm
Height (without stand)959 mm
Weight (without stand)23300 g
