TCL Alcatel Idol4 User Manual

L2 Repair Enhance Document TCL Communication Ltd.
Rev.
ONE TOUCH 6055K/P/Y/B/H Level 2 Enhance Repair Document
Page
1.0
38/72
All rights reserved. Transfer, copy, use or communication of this file is prohibited without authorization.
4.5 Disassembly process evaluation
We list the ONE TOUCH 6055 parts disassembly time, technique levels and disassembly methods as
below, for technique levels, Class 1 signifies easy to disassembly, Class 2 signifies normal to disassembly
and Class 3 signifies hard to disassembly.
Spare part
Time for
disassembly
Jigs for
disassembly
Difficulty Class
Remark
Furnished battery cover
10s
Class 2
Battery pack
15s
Class 2
Screws
8s
Screwdriver
Class 1
Main PCBA
15s
Tweezers
Plastic Flake
Class 2
Antenna PCBA
5s
Screwdriver
Plastic Flake
Class 1
Camera
2s
Plastic Flake
Class 1
Slide key FPC
3s
Tweezers
Class 1
Vibrator
3s
Tweezers
Soldering iron
Class 1
Top/ Bottom Speaker
box
8s
Tweezers
Soldering iron
Class 1
Furnished front casing
8s
Plastic Flake
Class 1
Audio Jack module
10s
Plastic Flake
Hot wind gun
Class 2
USB connector
10s
Plastic flake
Class 2
5 Disassembly Complete
 Explored view
