TCL Air Conditioner Service Manual
4
Model No. TAC-07CSC/K TAC-07CHSC/K TAC-09CSC/K TAC-09CHSC/K
Type Cooling Only Heating Pump Cooling Only Heating Pump
Control type Remote Remote Remote Remote
Rated cooling capacity Btu/h 7,000 7,000 9,000 9,000
Rated heating capacity Btu/h N/A 7,500 N/A 9,500
EER for cooling Btu/h.w 11.0 11.0 11.0 11.0
COP for heating W/W N/A 3.2 N/A 3.2
Moisture removal Liters/h 0.8 0.8 0.8 0.8
High dB(A) 38 38 38 38
Med. dB(A) 36 36 36 36
Indoor noise level at
cooling
Low dB(A) 32 32 32 32
Outdoor noise level dB(A) 50 50 50 50
Electrical Data
Power supply 220-240V~/50Hz
Voltage Range V 198~264 198~264 198~264 198~264
Cooling A 4.1 4.1 4.1 4.1
Rated current
Heating A N/A 4.1 N/A 4.1
Cooling W 880 880 880 880
Rated input
Heating W N/A 880 N/A 880
Refrigerating System
Refrigerant/Charge Gram R407C/700g R407C/700g R407C/700g R407C/700g
Type Rotary Rotary Rotary Rotary
Model ------------------ ----------------- ------------------ ------------------
LRA A ------ ------- ------ ------
Compressor
MFG ----------------- ----------------- ---------------- -----------------
Evaporator Louver fin and Grooved tube type (φ7)
Condenser Corrugated fin and Grooved tube type (φ9.53)
Expansion device Capillary tube
Defrosting system Microcomputer controlled reverse system
Fan System
Indoor air circulation m
3
/h 480 480 480 480
Indoor fan type Cross flow Cross flow Cross flow Cross flow
Cooling rpm 1230/1150/1000 1230/1150/1000 1230/1150/1000
1230/1150/1000
Heating rpm N/A 1230/1150/1000 N/A
1230/1150/1000
Dry rpm 1000 1000 1000 1000
Indoor fan speed
H/M/L
Sleep rpm 1000 1000 1000 1000
Indoor fan motor output W 12 12 12 12
Outdoor air circulation m
3
/h --- --- --- ---
Outdoor fan type Propeller fan Propeller fan Propeller fan Propeller fan
Outdoor fan speed rpm 860 860 860 860
Outdoor fan motor output W 31 31 31 31
Connections
Refrigerant coupling Flare type
Gas Inches 7/16 7/16 3/4 3/4
Connecting Pipe
Liquid Inches 3/4 3/4 7/16 7/16
Connecting Wiring
Size × Core
number
Drainage Pipe O.D 16mm
Others
Suitable area m
2
12~19 12~19 12~19 12~19
Indoor mm 770×250×179 770×250×179 770×250×179 770×250×179Net dimensions
(W x H x D)
Outdoor mm 700×255×540 700×255×540 700×255×540 700×255×540
Indoor kg 8.0 8.0 8 8
Net weight
Outdoor kg 31 32 31 32
Indoor mm 863×325×270 863×325×270 863×325×270 863×325×270Packing dimensions
(W x H x D)
Outdoor mm 803×380×598 803×380×598 803×380×598 803×380×598
Indoor kg 10 10 10 10
Gross weight
Outdoor kg 35 36 35 36
Loading Capacity 40’/40’HC 111/238/276 111/238/276 111/238/276 111/238/276
