Pin
No.
Terminal
Name
I/O Function
95 SH DO O Serial communication signal to
Sound Processor (Data signal
output)
96 SH DI I Serial communication signal to
Sound Processor (Data signal
input)
97 SH CK I Serial communication signal to
Sound Processor (Clock signal
input)
98 E DET I Unusual condition detect signal
input
99 CR
TIMER
- Not used, open
100
SD I Station detector signal input
from tuner unit (Z120)
15. Replacement Parts List
Notes:
- Important safety notice:
Components identified by mark have special characteristics
important for safety.
Furthermore, special parts which have purposes of fire-retardant
(resistors), high-quality sound (capacitors), low-noise (resistors),
etc. are used.
When replacing any of components, be sure to use only
manufacture’s specified parts shown in the parts list.
- The <IA> <IB> <IC> <ID> <IE> marks in Remarks indicate language
of instruction manual.
<IA>: English
<IB>: German, Italian, French
<IC>: Spanish
<ID>: Russian, Polish, Czech
<IE>: Netherlands, Danish, Swedish
- The parenthesized indications in the Remarks columns specify the
areas. (Refer to the cover page for area.)
- The marking [RTL] indicates that Retention Time is Limited for this
item. After the discontinuation of this assembly in production, the
item will continue to be available for a specific period of time. The
17
