Ref. No. Part No. Part Name & Description Pcs Remarks
R960 ERDS2FJ152 1/4W 1.5K 1
R961,62 ERDS2FJ223 1/4W 22K 2
R965,66 ERDS2FJ392 1/4W 3.9K 2
R969 ERDS2FJ272 1/4W 2.7K 1
R974 ERDS2FJ102 1/4W 1K 1
R975 ERDS2FJ223 1/4W 22K 1
R976 ERDS2FJ104 1/4W 100K 1
R986 ERDS2FJ152 1/4W 1.5K 1
R987,88 ERDS2FJ102 1/4W 1K 2
R990 ERDS2FJ104 1/4W 100K 1
R991 ERDS2FJ473 1/4W 47K 1
R993,94 ERDS2FJ104 1/4W 100K 2
R995 ERDS2FJ221 1/4W 220 1
R996,97 ERDS2FJ151 1/4W 150 2
R999 ERDS2FJ104 1/4W 100K 1
RL702 RSY0040M-0 RELAY 1
S901-08 EVQ11G05R SW,PUSH 8
S910-15 EVQ11G05R SW,PUSH 6
T701 RTP2N5B012 POWER TRANSFORMER 1
ETP76VST71SA /
T702 RTP1H3E001 POWER TRANSFORMER 1
VR901 EVQVBXFK124B V.R.,VOLUME 1
X151 RSXC4M33S02T OSCILLATOR 1 H0H433400001
X901 EF0EC6004T4 OSCILLATOR 1 EFOEC6004T4
X902 RSXD32K7S02 OSCILLATOR 1 H0A327200027
Z120 RAN0005EM-2 TUNER UNIT 1
Z701 ENC471D5ATRB B.P.F 1
J0LG00000006 /
Z901 B3RAD0000028 B.P.F 1
