Technics SL-1210MK7 User Manual

14
English
(14)
Anti-skating control
Arm clamp
Arm rest
Cue lever
1
Free the tone arm from the arm
rest and adjust horizontal balance
by turning the balance weight.
Hold the tone arm and turn the balance
weight in the arrow direction to adjust
the balance until the arm is approximately
horizontal.

Take care not to
allow the stylus tip
to touch the
turntable or main
unit.
Balance weight
Hold here
to turn
1
Turn the stylus pressure control
until “0“ comes to the centre line
of the rear of the tone arm.

Hold the balance
weight still while
doing this.
Preparation

Return the tone arm to the arm rest and fix it
with the arm clamp.
Horizontal balance Stylus pressure
Preparation

Remove the stylus cover, taking care not
to damage the stylus, then release the arm
clamp.

Lower the cue lever.

Turn the anti-skating control to “0”.
Adjustment
Balance weight
Arm clamp
Centre line
Stylus pressure
control
Hold here
to turn
Balanced and the tone
arm is parallel to the
turntable.
The balance weight is
too far forward.
The balance weight is
too far back.

Refer to the user's guide for your stylus for
the appropriate stylus pressure.
Note

Technics SL-1210MK7 Specifications

General

Type	Direct drive DJ turntable
Operation	Manual
Start-up time	0.7 s
Wow & flutter	0.025 %
Nominal speeds	33 1/3, 45, 78 RPM
Starting torque	1.8 kg/cm
Number of speeds	3
Product color	Black
Platter material	Aluminum
Shape	J-shaped tonearm
Overhang	15 mm
Tonearm type	Statically balanced tonearm
Tracking angle	32 °
Stylus pressure	4 g
USB port	-
AC input voltage	110 - 240 V
AC input frequency	50 - 60 Hz
Power consumption (typical)	8 W
Dust cover included	Yes

Weight and Dimensions

Depth	353 mm
Width	453 mm
Height	169 mm
Weight	9600 g
