Technics SL-1210MK7 User Manual

English
(20)
Pitch control
(fine adjustment to pitch)


To measure pitch
The four rows of strobe mirrors around
the edge of the turntable can assist you in
measuring pitch.
The strobe mirrors are lit by the strobe light
(LED lighting) synchronized with the precise
frequency of the digital control.
Always use this LED lighting to measure the
pitch.
ɿ
ɿ
ɿ
ヌプハフ
チチピハピ
チチ
パ
ノ
チ
ピハピ
テ
Strobe light
1
Press [RESET] to turn off the
RESET LED lamp.
2
Press the pitch range select
button to select the pitch range.

[×2] light on: ±16 %

[×2] light off: ±8 %
3
While the turntable is revolving
Slide [PITCH ADJ].

Pitch can be adjusted between approx.
–8 % and +8 % or approx. –16 % and
+16 % according to your selection.

The numbers represent approximate
percentages for your adjustment.
ヱリヵヤラチモュル
ンユヴユヵ
Pitch range select
button
RESET LED lamp
Pitch ADJ control
RESET button


To reset pitch to the preset value
Press [RESET].
The RESET LED lamp lights and the pitch
immediately returns to a preset value regardless
of the [PITCH ADJ] position.
(33-1/3, 45 or 78 rpm)

RESET LED on: Fixed to the preset value.

RESET LED off: Can be adjusted with
[PITCH ADJ].
Attention
 +6.4 % change in pitch when stationary
+3.3 % change in pitch when stationary
Normal turntable speed (33-1/3, 45 or 78
rpm) when stationary
-3.3 % change in pitch when stationary
Strobe
mirrors
20

Technics SL-1210MK7 Specifications

General

Type	Direct drive DJ turntable
Operation	Manual
Start-up time	0.7 s
Wow & flutter	0.025 %
Nominal speeds	33 1/3, 45, 78 RPM
Starting torque	1.8 kg/cm
Number of speeds	3
Product color	Black
Platter material	Aluminum
Shape	J-shaped tonearm
Overhang	15 mm
Tonearm type	Statically balanced tonearm
Tracking angle	32 °
Stylus pressure	4 g
USB port	-
AC input voltage	110 - 240 V
AC input frequency	50 - 60 Hz
Power consumption (typical)	8 W
Dust cover included	Yes

Weight and Dimensions

Depth	353 mm
Width	453 mm
Height	169 mm
Weight	9600 g
