2.2.2. Work table grounding
Put a conductive material (sheet) or steel sheet on the area where the traverse deck (optical
pickup) is placed, and ground the sheet. Refer to Fig.2-3.
Fig.2-3.
Caution:
The static electricity of your clothes will not be grounded through
the wrist strap.
So take care not to let your clothes tough the traverse deck (optical
pickup).
3. Precaution of Laser Diode
CAUTION:
This product utilizes a laser diode with the unit turned on, invisible
laser radiation is emitted from the pickup lens.
Wave length: 780 nm
Maximum output radiation power from pickup: 100 W/VDE
Laser radiation from pickup unit is safety level, but be sure the
followings:
1. Do not disassemble the pickup unit, since radiation from exposed
laser diode is dangerous.
2. Do not adjust the variable resistor on the pickup unit. It was
already adjusted.
3
