Ref. No. Part No. Part Name & Description Pcs Remarks
1 RKM0399-1S TOP CABINET 1
2 RHD30007-S SCREW 4
3 XTBS3+8JFZ1 SCREW 1
4 REZ1200-1 FFC 1
5 REZ1201-2 FFC 1
6 RYF0520B-1S CD LID ASS’Y 1
7 XTW3+8T SCREW 2
8 RKA0105-K RUBBER 4
9 RKA0106-N FOOT RING 4
10 RYP0896E-1S FRONT PANEL ASS’Y 1
10-1 RGB0025-A TECHNICS BADGE 1
11 XTBS3+8JFZ1 SCREW 3
12 XTB3+8JFZ SCREW 1
301 RAE0152Z-1 TRAVERSE DECK ASS’Y 1
301-1 SHGD113-1 RUBBER 3
301-2 SNSD38 SCREW 2
301-3 RAF0150A-1 OPTICAL PICK-UP 1
301-4 RDG0247 DRIVE GEAR 1
301-5 RDG0248 GEAR 1
301-6 RXQ0339 TRAVERSE MOTOR 1
301-7 RXQ0304-1 PLATE 1
301-8 XQN17+CG5 SCREW 1
301-9 XQN2+CQ5 SCREW 1
301-10 XQS17+A35FZ SCREW 1
302 RDV0056 BELT 1
303 RMB0549-1 SPRING 1
304 RMB0561 SPRING 1
305 RME0257 SPRING 1
47
