TECO JSMA-LC08AB User Manual

6
1-1-2 Confirming with Servo Motors
JSM
A – P S C 08 A H K B
Encode
Spline
Grease Seal



No No
K Yes No
O No Yes
A Yes Yes
TECO AC Servo
Product No.
Motor Series:
Series A
Motor Speed:
A: 1000 rpm
B: 2000 rpm
C: 3000 rpm
H: 1500 rpm
Motor Speed:
A: 1000 rpm
B: 2000 rpm
C: 3000 rpm
H: 1500 rpm
Encolder:
B : 2500 ppr
H : 8192 ppr
Motor ratio power
P5 : 50 W 20 : 2 KW
01 : 100 W 30 : 3 KW
03 : 300 W
04 : 400 W
05 : 550 W
08 : 750 W
10 : 1 KW
15 : 1.5 KW
AC input voltage
A : AC 220V
M:
Machinery BK


 : No BK
B:BK
IP67 (except shaft and connector)
