General| Analog Channels | 4 |
|---|---|
| Bandwidth | 200 MHz |
| Sample Rate | 2.5 GS/s |
| Record Length | 10 Mpoints |
| Digital Channels | 16 (optional) |
| Spectrum Analyzer Frequency Range | 9 kHz to 3 GHz |
| Digital Voltmeter | 4-digit |
| Vertical Resolution | 8 bits |
| Operating Temperature | 0 °C to +50 °C |
| Display | 9-inch WVGA (800x480) color display |
| Connectivity | USB, LAN, GPIB (optional) |
| Arbitrary Function Generator | 50 MHz |
| Trigger Modes | Edge, Pulse Width, Logic, Video, Runt, Rise/Fall Time, Setup/Hold |
| Input Impedance | 1 MΩ ±1% |
| Max Input Voltage | 300 VRMS |
| Trigger Types | Edge, Pulse Width, Logic, Video, Runt, Rise/Fall Time, Setup/Hold |
