Tektronix RSA5106B Technical Reference

Specifications
Table 26: Acquisition (cont.)
Characteristic Description
A/D Converter, nominal 16 bits, 200 MS/s (Standard Version and Option B40)
16 bits, 200 MS/s & 14 bits, 400 MS/s (Option B85, B125, B16x)
16 bits, 200 MS/s & 16 bits, 400 MS/s (Option B85HD, B125HD, B16xHD)
Span Sample Rate
Acquisition BW Record
Length
(Standard)
Record
Length
(option 53)
165MHz 200.0E+6 165E+6 1.34 5.37
125MHz 200.0E+6 125E+6 1.34 5.37
85 MHz 200.0E+6 165E+6 1.34 5.37
80 MHz 100.0E+6 80E+6 2.68 10.74
40 MHz 50.0E+6 40E+6 4.77 19.09
25 MHz 50.0E+6 40E+6 4.77 19.09
20 MHz 25.0E+6 20E+6 9.54 38.18
10 MHz 12.5E+6 10E+6 19.09 76.35
5 MHz 6.250E+6 5E+6 38.18 152.71
2 MHz 3.125E+6 2.5E+6 42.9 171.8
1 MHz 1.562500E+6 1.250E+6 85.9 343.6
500 kHz 781.250000E+3 625E+3 171.8 687.2
200 kHz 390.625000E+3 312.5E+3 343.6 1374.4
100 kHz 195.312500E+3 156.25E+3 687.2 2748.8
50 kHz 97.656250E+3 78.125E+3 1374.4 5497.6
20 kHz 48.828125E+3 39.0625E+3 2748.8 10995.1
10 kHz 24.4140625E+3 19.531250E+3 5497.6 21990.2
5 kHz 12.20703125E+3 9.765625E+3 10995.1 43980.5
2 kHz 3.0517578125E+3 2.44140625E+3 43980.4 175921.8
1 kHz 1.52587890625E+31.220703125E+3 87960.8 351843.6
500 Hz 762.939453125 610.3515625 175921.7 703687.3
200 Hz 381.4697265625 305.17578125 351843.4 1407374.5
Sampling Rate and Available Memory time in
RTSA/Time/Demod Mode, nominal
100 Hz 190.73486328125 152.587890625 703686.8 2814749.1
Minimum Acquisition Length in
RTSA/Time/Demod Mode, nominal
64 samples
Maximum Acquisition Length in
RTSA/Time/Demod Mode (Acquisition
BW Dependent), nominal
256,000,000 samples (Standard)
1,000,000,000 samples (Option 53)
