Tektronix TBS1102B User Manual

In XY format, the controls operate as follows:
■
The channel 1 Vertical Scale and Vertical Position controls set the
horizontal scale and position.
■
The channel 2 Vertical Scale and Vertical Position controls continue to set
vertical scale and position.
The following functions do not work in XY display format:
■
Autoset (resets display format to YT)
■
Autorange
■
Automatic measurements
■
Cursors
■
Reference or Math waveforms
■
Save/Recall ► Save All
■
Time base controls
■
Trigger controls
FFT
Options Settings Comments
Source waveform On or Off
Source Ch1 or Ch2
Window Hanning, Flattop, or
Rectangular
Typically, use Hanning for the best frequency
resolution, Flattop for the best magnitude
accuracy, and Rectangular for the best transient
analysis.
FFT Zoom X1, X2, X5, or X10
Reference
TBS1000B and TBS1000B-EDU Series Oscilloscopes User Manual 87

Tektronix TBS1102B Specifications

General

Bandwidth	100 MHz
Channels	2
Sample Rate	1 GS/s
Record Length	2.5 kpts
Vertical Sensitivity	2 mV/div to 5 V/div
Vertical Resolution	8 bits
Timebase Range	5 ns/div to 50 s/div
Display Type	TFT LCD
Display Resolution	480 x 234 pixels
Display	7-inch TFT LCD
Max Input Voltage	300 VRMS, CAT II
Trigger Types	Edge, Pulse, Video
Interfaces	USB 2.0
Power Supply	100-240 VAC, 50/60 Hz
Input Impedance	1 MΩ ±2%, 13 pF ±3 pF
