Getting Started
6
TDS 200-Series Extension Module Instructions
Checking Module Installation
To check that the extension module is correctly installed, turn on the
oscilloscope. The power–up screen should include the message
”Extension Module Passed”. If the oscilloscope does not recognize
the extension module at power-up, do the steps in Troubleshooting
Module Installation below.
Troubleshooting Module Installation
If the oscilloscope does not recognize the extension module at
power-up, do the following steps:
1. Turn off the oscilloscope.
2. Follow the ESD precautions listed on page 3.
3. Disconnect all cables from the extension module.
4. Remove the extension module (refer to page 4).
5. Examine the oscilloscope option connector for bent, broken, or
missing pins. If any pins are bent, carefully straighten them out.
6. Reinstall the extension module onto the oscilloscope.
7. Turn on the oscilloscope. If the oscilloscope still does not show
the module installed, contact the nearest Tektronix service center.
