Tektronix TDS 200-Series Instructions

TDS2HM Hard Copy Module
8
TDS 200-Series Extension Module Instructions
Hard Copy Setup
To setup the TDS2HM Module, do the following:
1. Turn on the oscilloscope.
2. Push UTILITY
 Options  Hard Copy Setup.
3. Push the menu button next to the menu item to change the
settings to match those of your printer device. The following
table lists the settings you can change.
The oscilloscope stores these settings until you change them.
Turning off the oscilloscope does not erase these settings.
Menu Settings Comments
Layout Portrait, Landscape Hard copy output orientation
Format Epson, ThinkJet, DeskJet,
LaserJet, BMP, PCX,
EPSIMAGE, INTERLEAF,
DPU411
1
, DPU412
1
Type of device connected to
the hard copy port
Port
(TDS2CM and
TDS2MM only)
Centronics, RS-232, GPIB Module port to which the
printer is connected
Abort
Hardcopy
Stops sending screen data to
the hard copy device
1
Refer to Read Me First on page 1 for more Seiko printer information.
