Tektronix TDS 684A Programming Manual

Command Groups
TDS Family Oscilloscope Programmer Manual
2–25
Table 2–19: Trigger Commands
Header Description
TRIGger Force trigger event; Return parameters
TRIGger:DELay Delay trigger level to 50%
TRIGger:DELay:BY Delay by time or events
TRIGger:DELay:EDGE? Return delay trigger parameters
TRIGger:DELay:EDGE:COUPling Delay trigger coupling
TRIGger:DELay:EDGE:SLOpe Delay trigger slope
TRIGger:DELay:EDGE:SOUrce Delay trigger source
TRIGger:DELay:EVENTS? Return delay trigger event parameters
TRIGger:DELay:EVENTS:COUNt Delay by events count
TRIGger:DELay:LEVel Delay trigger level
TRIGger:DELay:TIMe Time for delay by time
TRIGger:DELay:TYPe Delay trigger, edge
TRIGger:MAIn Main trigger level to 50%
TRIGger:MAIn:EDGE? Return main edge trigger parameters
TRIGger:MAIn:EDGE:COUPling Main trigger coupling
TRIGger:MAIn:EDGE:SLOpe Main trigger slope
TRIGger:MAIn:EDGE:SOUrce Main trigger source
TRIGger:MAIn:HOLDoff? Return main trigger holdoff value
TRIGger:MAIn:HOLDoff:ACTUal?
(TDS 684A & 7XXA)
Return main trigger holdoff value in seconds
TRIGger:MAIn:HOLdoff:BY
(TDS 684A & 7XXA)
Main trigger holdoff default
TRIGger:MAIn:HOLdoff:TIMe
(TDS 684A & 7XXA)
Main trigger holdoff time
TRIGger:MAIn:HOLdoff:VALue
(Not in TDS 684A & 7XXA)
Main trigger holdoff value
TRIGger:MAIn:LEVel Main trigger level
TRIGger:MAIn:LOGIc?
(TDS 5XXA, 6XXA, & 7XXA)
Returns main logic trigger parameters
TRIGger:MAIn:LOGIc:CLAss
(TDS 5XXA, 6XXA, & 7XXA)
Logic trigger input usage
TRIGger:MAIn:LOGIc:FUNCtion
(TDS 5XXA, 6XXA, & 7XXA)
Logic trigger input combining
TRIGger:MAIn:LOGIc:INPut?
(TDS 5XXA, 6XXA, & 7XXA)
Return main logic trigger input settings
