Nominal Traits
TDS 500B, 600B and TDS 700A Service Manual
1–13
Table 1–9: Nominal Traits — Mechanical
Name Description
Cooling Method Forced-air circulation with no air filter. Clearance is required.
Construction Material Chassis parts constructed of aluminum alloy; front panel constructed of plastic laminate;
circuit boards constructed of glass laminate. Cabinet is aluminum and is clad in Tektronix
Blue vinyl material.
Finish Type Tektronix Blue vinyl-clad aluminum cabinet
Weight Standard Digitizing Oscilloscope
14.1 kg (31 lbs), with front cover.
24.0 kg (53 lbs), when packaged for domestic shipment
Rackmount Digitizing Oscilloscopes
14.1 kg (31 lbs) plus weight of rackmount parts, for the rackmounted Digitizing
Oscilloscopes (Option 1R).
Rackmount conversion kit
2.3 kg (5 lbs), parts only; 3.6 kg (8 lbs), parts plus package for domestic shipping
Overall Dimensions Standard Digitizing Oscilloscope
Height: 193 mm (7.6 in), with the feet installed
Width: 445 mm (17.5 in), with the handle
Depth: 434 mm (17.1 in), with the front cover installed
Rackmount Digitizing Oscilloscope
Height: 178 mm (7.0 in)
Width: 483 mm (19.0 in)
Depth: 558.8 mm (22.0 in)
