Maintenance
TDS3000 Series Service Manual
6–7
You will need the following tools to remove and replace all the modules in the
oscilloscope.
H
Torque-limiting screwdriver, 12 in ⋅ lb (1.3 N ⋅ m) range with Torx® T-10
and T-15 tips (If you are using a magnetic screwdriver with interchangeable
bits, the T-15 bit must be a long bit, at least 5 cm (2 in) overall length).
H
Screwdriver with
1
@
8
inch flat blade
H
3
@
16
inch nut driver
H
Needle-nose pliers
You will need a
1
@
8
inch flat-bladed screwdriver to remove the handle.
Removal. Use this procedure to remove the handle.
1. Use the
1
@
8
inch flat-bladed screwdriver to pry the hub cover off of each side
of the handle.
2. Raise the handle to its full upright position.
3. Locate the handle hub on the display side of the oscilloscope.
NOTE. Do not remove the screw at the center of the handle hub.
4. Use the needle-nose pliers to pull the metal pin in the display-side hub
outward approximately 5 mm (0.2 in). If you accidentally pull the metal pin
all the way out, reinsert it half way. See Figure 6–1.
Tools Required
Handle
To Next Page
