Teldat WWAN Enabler User Manual

• SA UL 2 × 2 MIMO: n38, n41, n48, n77, n78, n79
• DL MIMO:
• DL 2 x 2 MIMO are supported on all bands
• SA DL 4 × 4 MIMO: n1, n2, n3, n7, n25, n30, n38, n40, n41, n48, n66, n70,
n77, n78, n79
• NSA DL 4 × 4 MIMO: n1, n2, n3, n7, n25, n30, n66, n38, n40, n41, n48,
n70, n77, n78, n79
• Subcarrier Spacing (SCS) modes: FDD can only support 15KHz, and TDD can
only support 30KHz.
• BW per CC: Up to 100MHz.
• LTE:
• 3GPP Release 16
• FDD: B1, B2, B3, B4, B5, B7, B8, B12, B13, B14, B17, B18, B19, B20, B25,
B26, B28, B29, B30, B32, B66, B71
• TDD: B34, B38, B39, B40, B41, B42, B43, B48
• LAA: B46
• UL modulation: up to 256QAM.
• DL modulation: up to 256QAM.
• Carrier Aggregation: DL: Up to 5CC, UL: 2CC intra-band continuous and inter-
band CA.
• DL MIMO
• 2x2 DL MIMO are supported on all bands
• 4x4 DL MIMO can be supported on bands B1, B2, B3, B4, B7, B25, B30,
B38, B40, B41, B42, B43, B48, B66
• WCDMA:
• 3GPP Release 8 and Release 99
• B1, B2, B4, B5, B8, B19
Speed (DL/UL) The data rates presented are only theoretical, meaning the actual value will de-
pend on the network's condition.
FN980:
• 5G-NR
• Downlink:
• 12 layers LTE + TDD (100MHz BW, 256QAM, 4x4): ~3.33Gbps @ 95% duty
cycle
• 16 layers LTE + FDD (20MHz BW, 256QAM, 4x4): ~2.03Gbps
• Uplink:
• 2 layers LTE + TDD (100MHz BW, 256QAM, SISO): ~0.66Gbps @ 92.5%
duty cycle
• 2 layers LTE + FDD (20MHz BW, 256QAM, SISO): ~0.32Gbps
• LTE:
• DL Cat 20: up to 20 layers (Up to 2Gbps)
• UL Cat 18: 2CC intra-band contiguous and inter-band, 256QAM (Up to 210
Mbps)
• Supported BW: 1.4–20 MHz, per 3GPP specs for supported bands
• HSPA+ Cat 24/6: 42Mbps/5.76Mbps
RM520N-GL:
• 5G-NR
Teldat S.A.
Technical Information
WWAN Enabler 31
