49
TermaTech A/S, Gunnar Clausens Vej 36, DK-8260 Viby J www.termatech.com 21-12-2023 LP Item no. 99-274
8.8 Adjustment of the draft in the door
Type: All models in the TT21 series
8.9 Installation of air intake for connection of external combustion air, item number 09-170
Type: all models in the series.
Weaker / less draft in the door:
Tighten the two screws on the top and bottom
magnet (clockwise). Move magnets away from
the door.
Stronger / more draft in the door:
Loosen the two screws on the top and bottom
magnet (counterclockwise). Move magnets
closer to the door.
Note: We recommend a draft of 4 to 6 kg. The
door must not hit the magnet. Distance
between door and magnet should be a
minimum of 1mm.
2. Install the air intake as shown in the picture
above. Use the four nuts and four flat washers
provided in the cardboard box. First, attach the
flat washer, then the nut. One nut and one flat
washer for each threaded rod. Refer to the black
arrows.
1. Open the door to the wood
compartment. Remove the heat
shield and install the air nozzle
here. Refer to the black arrow.
