thomann the t.racks DSP 4x4 Amp100V User Manual

4 Installation and starting up
Unpack and check carefully there is no transportation damage before using the unit. Keep the
equipment packaging. To fully protect the product against vibration, dust and moisture during
transportation or storage use the original packaging or your own packaging material suitable
for transport or storage, respectively.
Create all connections while the device is o. Use the shortest possible high-quality cables for
all connections. Take care when running the cables to prevent tripping hazards.
The gure schematically shows how the device can be controlled via a computer's USB port.Conguration example
Installation and starting up
12
DSP 4x4 Amp 4.250, DSP 4x4 Amp100V
Controller
