5
PRE-OPERATION INSTRUCTIONS
NOTE: (color fastness) Before using carpet cleaning chemicals, test on an inconspicuous part
of the carpet for color fastness. Place the solution on a small piece of clean white material or
tissue, then rub the carpet vigorously. Excessive amounts of dye showing on the material would
indicate that the colors are not fast, and should not be wet cleaned.
1) Fill the solution tank with 9 gallons of warm
water.
WARNING: DO NOT overfill.
2) Measure carpet cleaning solution per
manufacturers recommended ratio into the
clean water tank. DO NOT use the waste tank
to fill the solution tank as debris could damage
the pump or block the jet. WARNING: DO NOT
exceed 150°F (65° C)
3) Add defoamer solution per manufacturer’s
instructions as needed.
OPERATION
1) Plug main power cable into outlet.
WARNING: This machine must be properly
grounded.
2) Press the VACUUM switch to the ON
position. Then press the PUMP switch ON and
the BRUSH switch to the ON position.
3) Lower carpet brush. Push brush lowering
pedal forward to lower brush. Push down and
back to raise bush.
4) Press and hold the solution switch to
apply the cleaning solution. Pull the machine
backwards at the same time to clean the
carpet. Stop the solution spray about 12”
(30cm) before the end so all of the solution
is vacuumed up. Slightly overlap the next
cleaning pass to prevent streaking. A two (2)
wet pass maximum is recommended to avoid
overwetting. After a few passes, check the
waste tank to see that no foam is present. Add
extra defoamer if necessary.
5) Make sure to empty the recovery (top) tank
when it is approximately 3/4 full. Do not refill
the solution tank without emptying all the
contents of the recovery tank first.
Solution Switch
Brush Lowering Pedal
Recovery Tank
Solution Tank
Vacuum Shoe
Brush and Spray
To Next Page
