6
STORAGE
WHEN CLEANING IS FINISHED:
1) Connect the drain solution hose (gray hose
with brass connector) to the solution fitting at
the front of the machine and place the other
end into the recovery tank. Turn on the PUMP
switch. This will pump the remaining solution
into the recovery tank for easy drainage.
2) To disconnect the solution hose, push in on
the ring of the solution filling. Switch off the
machine, remove power plug from the socket,
and empty the waste tank. Leave waste tank
open when storing.
3) Leave brush raised for storage.
Brush Lowering Pedal
Drain Hose
ACCESSORIES / TOOLS
(OPTIONAL)
Recovery Hose
Connection
Solution Hose
Connection
For upholstery cleaning and hard to reach
areas.
Attach recovery hose to recovery hose
connection of vacuum shoe. Connect the
accessory solution hose to the solution hose
connection at the front of the machine by
pushing back the locking ring to fit. Turn on
vacuum and pump.
ROUTINE MAINTENANCE
DAILY
1) Check the spray jet for blockage and a uniform spray pattern. Remove jet and blow through to
clean. Do not use a pin as this may cause damage to the jet.
2) Check and remove any debris or lint build-up from the vacuum head, brush, and brush
housing.
3) Always wash out the tanks with clean water after use. To do this, pour clean water into the
solution tank and spray through spray tip to clear chemical residue from the pump, lines, and
spray tip. Allow the vacuum to run for a few minutes after use to aid the machine in drying out
and to help prevent bacteria and odors.
WEEKLY
Inspect hoses (unseen blockages sometimes occur), hose cuffs, and the rubber seal on the
recovery tank lid. The main cable, plug, and switches should also be examined for damage.
NOTE: It is advisable to store the unit with the recovery tank lid removed.
CAUTION: THIS UNIT MUST BE PROTECTED FROM FREEZING. Damage from freezing could
cause machine to malfunction.
