ControlsSystem
Maintenance
AdjustingtheTractionControl
Iftractioncontroldoesnotengageoritslipsduring
operation,anadjustmentisrequired.
1.MovetractioncontroltoDisengagedposition.
2.Toincreasecabletension,loosenfrontcablejam
nutandtightenbackcablejamnut(Figure49)until
aforceof10-13lb.isrequiredtoengagetraction
control.
Measuretheforceatthecontrolknob.
Figure49
1.Tractioncable
2.Service/parkingbrake
cable
3.Tightenfrontcablejamnut.
4.Checkcontroloperation.
AdjustingtheReelControl
Ifreelcontroldoesnotengageoritslipsduring
operation,anadjustmentisrequired.
1.Makesuretractioncontrolisproperlyadjusted;refer
toAdjustingtheTractionControl.
2.Toincreasecabletension,loosenfrontcablejamnut
andtightenbackcablejamnut(Figure50)(located
ontopofgearbox)untilthereelcableforceadds7
to10lbs.ofadditionalhandleforcemeasuredatthe
controlknob.
Note:Iftractioncontrolhandleforceis12lbs.,the
combinedtractionandreelforceshouldbe19to
22lbs.
Figure50
1.Reelcontrolcable
3.Tightenfrontcablejamnut.
4.Checkcontroloperation.
30
