DriveSystem
Maintenance
ChangeFrontDifferentialOil
FourWheelDriveOnly
ServiceInterval:Every800hours
1.Positionvehicleonalevelsurface,stopengine,
engageparkingbrakeandremovekeyfromignition
switch.
2.Cleanareaarounddrainplugonsideofdifferential.
Placedrainpanunderdrainplug.
Figure54
1.Frontdifferential
3.Drainplug
2.Fill/checkplug
3.Removedrainplugandletoilowintodrainpan.
Reinstallandtightenplugwhenoilstopsdraining.
4.Cleanareaaroundll/checkplugonsideof
differential.
5.Removell/checkplugandadd10W30oiluntiloil
isuptohole.
6.Re–installll/checkplug.
InspectConstantVelocityBoot
FourWheelDriveOnly
ServiceInterval:Every200hours
Afterevery200operatinghours,inspectconstant
velocitybootforcracks,holesoralooseclamp.
AdjustingShiftCables
ServiceInterval:Aftertherst10hours
Every200hours
1.MoveshiftlevertoNeutralposition.
2.Removeclevispinssecuringshiftcablestotransaxle
shiftarms.
Figure55
1.Shiftarm(1st–Rev.)3.Shiftarm(High–low)
2.Shiftarm(2nd–3rd)
3.Loosenclevisjamnutsandadjusteachclevisso
cablefreeplayisequalforwardandbackwardrelative
toholeintransaxleshiftarm(Withtransaxlelever
freeplaytakenupinsamedirection).
4.Reinstallclevispinsandtightenjamnutsafter
adjustmentshavebeenattained.
AdjustingHigh–lowCable
ServiceInterval:Every200hours
1.MovedifferentiallocklevertoOffposition.
2.Loosenjamnutssecuringdifferentiallockcableto
bracketontransaxle.
3.Adjustjamnutstoobtain.035”±.025”gapbetween
springhookandO.D.ofholeintransaxlelever.
4.Tightenjamnutsafteradjustmenthasbeenattained.
AdjustingDifferentialLock
Cable
ServiceInterval:Every200hours
1.MovedifferentiallocklevertoOffposition.
2.Loosenjamnutssecuringdifferentiallockcableto
bracketontransaxle(Figure56).
45
