CompressionSystemAssembly2
Figure114
1.PushRod6.Piston
2.HeadGasket
7.PistonPin
3.DowelPin8.ValveTappet
4.PistonRingSet9.ConnectingRodAsm.
5.WristPinClip
CompressionSystem:ServiceandRepairs
Page7–4
1P65F-2ServiceManual
3429-270RevA
