ChargingtheBattery
ServiceInterval:Every25hours
Yearlyorbeforestorage
Electric-StartModelOnly
WARNING
CALIFORNIA
Proposition65Warning
Batteryposts,terminals,andrelated
accessoriescontainleadandleadcompounds,
chemicalsknowntotheStateofCalifornia
tocausecancerandreproductiveharm.
Washhandsafterhandling.
Chargethebatteryfor24hoursinitially,thenmonthly(every
25starts)orasneeded.Alwaysusethechargerinasheltered
area,andchargethebatteryatroomtemperature(about70°
F,or22°C)wheneverpossible.
1.Connectthechargertothemachinewiringharness
locatedbelowtheelectric-startbutton(Figure25).
Figure25
2.Plugthechargeintoawalloutlet.
Note:Whenthebatterynolongerholdsacharge,
recycleordisposeofthelead-acidbatteryaccording
tolocalcodes.
Note:Yourbatterychargermayhavea2-colorLEDdisplay
thatindicatesthefollowingstatesofcharging:
•Aredlightindicatesthatthechargerischargingthe
battery.
•Agreenlightindicatesthatthechargerisfullychargedor
thechargerisdisconnectedfromthebattery.
•Aashinglightthatalternatesbetweenredandgreen
indicatesthatthebatteryisnearlyfullycharged.Thisstate
lastsonlyafewminutesuntilthebatteryisfullycharged.
ReplacingtheFuse
Electric-StartModelOnly
Note:Ifthebatterydoesnotchargeortheenginedoesnot
runwiththeelectricstarter,thefusemaybeblown.Replace
itwitha40-ampplug-intypefuse.
1.Raisethereardeectorandlocatethebattery
compartment(Figure26).
Note:Thereisanadhesive-backedcoveringthat
protectsthebatterycompartment.
Figure26
1.Reardeector
3.Battery
2.Screw
4.Batterycompartment
2.Wipeawayanydebrisinthebatterycompartmentarea
andremovetheadhesive-backedcovering.
3.Removethescrewthatsecuresthebattery
compartment,pulloutthebattery,andlocatethefuse
(Figure26andFigure27).
16
