2
InstallingtheFuelTankand
theFuelLine
Partsneededforthisprocedure:
2
Self-tappingscrew
1Fueltank
Procedure
1.Slidetheendofthefuellineontotheelbowtting
(Figure4).
G002527
1
2
3
4
Figure4
1.Fueltank3.Fuelline
2.Elbowtting
4.Fuellineclamp
2.Securethefuellineinplacewiththefuellineclamp
(Figure4).
3.Slidetheplasticclipsonthefrontofthefueltank
ontothefueltankmount(Figure5).
Figure5
1.Plasticclip(2)
4.Securethebottomofthefueltanktothefueltank
bracketbyinstallingtheself-tappingscrewsfromthe
bottom.Torquethescrewsto40to50in-lb(4.5
to5.6N-m).Donotovertightenthescrews.
3
FillingtheCrankcasewithOil
NoPartsRequired
Procedure
Theenginecrankcaseisshippedwithoutoil.Youmust
llitwithapproximately29oz.(0.85l)ofoilbefore
startingtheengine.RefertoCheckingtheEngineOil
Levelforoilspecicationsandinstructions.
