ReplacingtheDriveBelt

Ifdrivebeltbecomesworn,oil-soaked,excessivelycracked,

frayed,orotherwisedamaged,replacethebelt.

1.Removethe4boltsthatholdthedrive-beltcover

(Figure30)inplace.

Figure30

1.Drivebeltcover

Note:Thelowerfrontcornerofthedrivebeltcover

isfasteneddownwithasmallerbolt,awasher,anda

locknut.

2.Removethebeltfromtherotorpulley.

Figure31

1.Rotorpulley5.Idlerpulley

2.Idlerarmbrake6.Enginepulley

3.Drivebelt7.Tabsontheidlerarm

4.Idlerarm

3.Pressdownontheidlerarmandremovethebeltfrom

betweenthetabontheidlerarmbrakeandtherotor

pulley.

Note:Theenginepulleybeltguideisveryclosetothe

pulley,andthebeltmaynottthroughthegap.

4.Twistthebeltoutinfrontofthebeltguidesothatthe

beltiswedgedbetweenthebeltguideandtheengine

pulley.

5.Insertascrewdriverintotheholeinthebeltguideas

showninFigure32,andexthebeltguidetowardthe

rotorpulleyenoughtopullthebeltthroughthegap.

Figure32

1.Beltguide2.Enginepulley

Note:Takecarenottodistortordamagethebelt

guide.

6.Toinstallthenewdrivebelt,reversethestepsabove.

Important:Ensurethatyouinstallthedrivebelt

sothatitsitsabovethe2tabsontheidlerarmand

belowtheidlerarmbrake(Figure31).

7.Installthedrivebeltcoverwiththefastenersthatyou

removedinstep1.
