OperatingtheAuger/Impeller
Drive
1.Toengagetheauger/impellerdrive,squeezethe
righthand(auger/impeller)levertothehandgrip
(Figure31).
Figure31
2.Tostoptheaugerandimpeller,releasetherighthand
lever.
Important:Whenyouengageboththe
auger/impellerleverandthetractionlever,the
tractionleverlockstheauger/impellerleverdown,
freeingyourrighthand.Toreleasebothlevers,
simplyreleasethelefthand(traction)lever.
3.Iftheaugerandimpellercontinuetorotatewhenyou
releasetheauger/impellerlever,donotoperatethe
machine.Checktheauger/impellercable(referto
CheckingandAdjustingtheAuger/ImpellerCable)
andadjustitifnecessary.Otherwise,takethemachine
toanAuthorizedDealerforservice.
WARNING
Iftheaugerandimpellercontinuetorotate
whenyoureleasetheauger/impellerlever,you
couldseriouslyinjureyourselforothers.
Donotoperatethemachine.Takeittoan
AuthorizedServiceDealerforservice.
OperatingtheQuickStick™
HoldthebluetriggercapdowntousetheQuickStickto
movethedischargechuteandthechutedeector.Releasethe
triggercaptolockthedischargechuteandchutedeector
intoposition(
Figure32).
Figure32
MovingtheDischargeChute
HoldthebluetriggercapdownandmovetheQuickStick
tothelefttomovethedischargechutetotheleft;movethe
QuickSticktotherighttomovethedischargechutetothe
right(
Figure33).
g018894
Figure33
•Ifthechutedoesnotmove,refertoAdjustingthe
DischargeChuteLatch.
•Ifthechutedoesnotturnasfartotheleftasitdoesto
theright,ensurethatthecableisroutedtotheinsideof
thehandles.RefertoInstallingtheUpperHandle.
•Ifthechutedoesnotlockintoplacewhenyoureleasethe
triggercap,refertoAdjustingtheDischargeChuteLatch.
MovingtheChuteDeector
HoldthebluetriggercapdownandmovetheQuickStick
forwardtolowerthechutedeector;moveitrearwardtoraise
thechutedeector(Figure34).
17
