1
InstallingtheUpperHandle
Partsneededforthisprocedure:
2Handlebolts
2
Curvedwashers
2Locknuts
Procedure
1.Liftandrotatetheupperhandleandpositionitover
thelowerhandle.
2.Securetheupperhandlewith2handlebolts,2curved
washers,and2locknutsfromtheloosepartsbag
(Figure3).
g019003
Figure3
2
InstallingtheTractionControl
Linkage
NoPartsRequired
Procedure
1.Removethehairpincotterandwasherfromthelower
endofthespeedcontrolrodandinsertthelowerend
oftherodintothelowerlinkarmsothatthebentend
ofthespeedcontrolrodfacesrearward(Figure4).
g019004
Figure4
2.Securethelowerendofthespeedcontrolrodwiththe
washerandhairpincotterthatyoupreviouslyremoved.
3.Removethehairpincotterandtheouterwasherfrom
thetrunnionontheupperendofthespeedcontrol
rod(Figure5).
Figure5
1.Speedselectorlever
3.Innerwasher
2.Trunnion
4.Outerwasher
Note:Tomakeinstallationeasier,leavetheatwasher
onthetrunnion(Figure5).
4.ShiftthespeedselectorleverintoPositionR2.
5.Rotatethelowerlinkarmfullyupward
(counterclockwise)(Figure6).
Figure6
6.Liftuponthespeedcontrolrodandinsertthetrunnion
intotheholeinthespeedselectorlever(Figure5).
8
