Toro 38818 User Manual

Figure5
1.Axlepin2.Holeinwheelhuband
outeraxleholealigned
Note:Ifyouinstalltirechains(optional),youmust
installtheaxlepinsthroughtheouteraxleholes.
2
InstallingtheSpeedSelector
Rod
Partsneededforthisprocedure:
1
Speedselectorrod
1
Cotterpin
1Flatwasher
Procedure
1.Pullthespeedselectorarm(Figure6)tothemost
outwardposition.
Figure6
1.Speedselectorarm3.Speedselectorrod
2.Flatwasherandcotterpin
2.Movethespeedselectorlever(Figure14)onthe
controlpaneltotheR(Reverse)position.
3.Installthespeedselectorrodintothespeedselector
arm,addaatwasherontheselectorrod,andsecureit
withacotterpin(Figure6).
3
InstallingtheTractionRod
Partsneededforthisprocedure:
1Flangelocknut
Procedure
1.Threadtheangelocknut(angesideup)ontothe
bottomofthetractioncontrolrod,belowtheloopin
thelowertractionrod(Figure4).
2.Adjustthe2angenutsupordownonthetraction
roduntilthedistancebetweenthetopofthehandgrip
andthebottomofthetractioncontrolleveris
approximately4-1/2inches(11.4cm)asshownin
Figure7.
10

Toro 38818 Specifications

General

Brand	Toro
Model	38818
Category	Snow Blower
Language	English
