Themachineisnowabletobepushedbyhand.
g017303
1 2
3
Figure25
1.Bypassleverlocation
3.Leverpositionforpushing
themachine
2.Leverpositionfor
operatingthemachine
6.Whennished,ensurethekeyhasbeenreturnedtothe
Stoppositiontoavoiddrainingthebatterycharge.
Ifthemachinefailstomovetheelectricbrakemaystillbe
engaged.Ifnecessarytheelectricbrakecanbereleased
manually.RefertotheReleasingtheElectricBrake(page34)
procedureinDriveMaintenance.
ToOperatetheMachine
Movethebypassleversrearwardthroughthekeyholeand
downtolocktheminplaceasshowninFigure25.Ensure
thisisdoneforeachlever.
GrassDeector
Themowerhasahingedgrassdeectorthatdisperses
clippingstothesideanddowntowardtheturf.
DANGER
Withoutthegrassdeector,dischargecover,or
completegrasscatcherassemblymountedin
place,youandothersareexposedtobladecontact
andthrowndebris.Contactwithrotatingmower
blade(s)andthrowndebriswillcauseinjuryor
death.
•Neverremovethegrassdeectorfromthemower
becausethegrassdeectorroutesmaterialdown
towardtheturf.Ifthegrassdeectorisever
damaged,replaceitimmediately.
•Neverputyourhandsorfeetunderthemower.
•Nevertrytocleardischargeareaormower
bladesunlessyoumovethebladecontrolswitch
toOffandrotatetheignitionkeytoOff.Also
removethekeyandpullthewireoffthespark
plug(s).
ConvertingtoSideDischarge
Mode
DANGER
Openholesinthemowerexposeyouandothersto
throwndebris.Debristhrownoutoftheholesinthe
mowercancauseinjury.
•Neveroperatethemowerwithouthardware
mountedinallholesinthemower.
•Installhardwareinthemountingholeswhen
youremovethebafe.
1.Stoptheengineandremovetheignitionkey.
2.RemovethemowerasdescribedinyourOperator’s
Manual.
3.Turnthemowerupsidedown.
4.Removetheexistingmowerbladesinstalledonyour
deck;refertotheRemovingtheBlades(page36)for
moreinformation.
5.Removeanydebrisandgrassclippingsfromthe
undersideofthedeck.
6.Removethebafeassemblytotherightsideofthe
mowerdeckwithacarriagebolt(5/16x3/4inch)and
2angenuts(5/16inch)asshownin
Figure26.
22
