Figure76
1.Positionthebeltcover3.Ensurethetabisunder
themetalcatch
2.Slidebeltcoverunderthe
sidecatches
ReplacingtheHydraulicPump
DriveBelt
1.DisengagethePTOandsettheparkingbrake.
2.Stoptheengine,removethekey,andwaitforall
movingpartstostopbeforeleavingtheoperating
position.
3.Removemowerbelt.RefertoReplacingtheMower
BeltinMaintenance.
4.Raisethemachineandsupportitwithjackstands
(
Figure77).
Figure77
1.Idlerpulley
5.Lefthandhydraulicpump
pulley
2.Clutchpulley6.Squareholeinidlerarm
3.Pumpdrivebelt7.Idlerspring
4.Righthandhydraulicpump
pulley
5.Usearatchetinthesquareholeintheidlerarmto
removetheidlerspring(Figure77).
6.Unhooktheidlerspringfromtheframe(Figure77).
7.Removethebeltfromthehydraulicunitdrivepulleys
andtheenginepulley
8.Installthenewbeltaroundenginepulleyandthe
twodrivepulleys.
9.Usingaratchetinthesquareholeintheidlerarm,
installtheidlerspringtotheframe(
Figure77).
10.Installthemowerbelt.RefertoReplacingthe
MowerBelt.
50
