Operation
ProductOverview
g220753
Figure8
1.Rotorblades8.Powercontrolbar
2.Beltcover(notshown)
9.Upperhandle
3.Chutedeector10.Cord
4.Chutedeectortrigger11.Chutecontrolrod
5.Dischargechutehandle
12.Handleknobs
6.Cordlock
13.Dischargechute
7.Interlockbutton(key)
Important:Thismachineisintendedforoutdoor,
residentialuseonly.Donotuseitindoorsorforcommercial
orindustrialpurposes.
ConnectingtoaPower
Source
Toreducetheriskofelectricshock,thismachinehasapolarized
plug(i.e.,onebladeiswiderthantheother).Useonlya
polarizedplug,UL-listed(CSAcertiedinCanada)extension
cordrecommendedforoutdooruse.Apolarizedplugwilltina
polarizedcordonlyoneway.Iftheplugdoesnottfullyinthe
cord,reversethecord.Ifitstilldoesnott,purchaseapolarized
extensioncord.Ifyouhaveapolarizedextensioncordandthe
extensioncordplugdoesnottfullyintothewallreceptacle,
reversetheplug.Ifitstilldoesnott,contactaqualiedelectrician
toinstalltheproperoutlet.Donotchangethemachineor
extensioncordpluginanyway.
DANGER
Contactwithwaterwhileoperatingthemachinecould
causeelectricshock,causinginjuryordeath.
•Donothandletheplugorthemachinewithwet
handsorwhilestandinginwater.
•Useonlyanextensioncordrecommendedfor
outdoorcold-weatheruse.
ExtensionCordLengthMinimumWireGauge
(A.W.G.)
25feet
14
50feet
14
100feet
12
150feet
10
Note:Donotuseanextensioncordover48meters(150feet).
Important:Checktheextensioncordfrequentlyduring
useforholesorcracksintheinsulation.Donotusea
damagedcord.Donotrunthecordthroughstandingwater.
Note:Topreventtheextensioncordfromdisconnectingduring
operation,usethecordlockontheupperhandlebeforeyou
connectittothemachine(Figure9).
g220754
Figure9
1.Cordlock
2.Extensioncord
WARNING
Theelectricalcordcangetdamaged,causingashock
orre.
Thoroughlyinspecttheelectricalcordbeforeusingthe
snowthrower.Ifthecordisdamaged,donotoperate
thesnowthrower.Repairorreplacethedamagedcord
immediately.ContactanAuthorizedServiceDealerfor
assistance.
6
