Toro PowerCurve 1800 User Manual

g013469
Figure14
1.Screws
2.Removeanddiscardtheoldscraper.
3.Installthenewscraper,andfastenitsecurelywiththe4
screwsthatyoupreviouslyremoved.
ReplacingtheRotor
1.Removethescrewsthatsecuretherightsideplatetothe
machineframe(Figure15).
g013463
Figure15
2.Removetherotorpin(Figure16).
g013464
Figure16
1.Rotorpin
3.Removetheoldrotor.
4.Installthenewrotorbyinsertingtheendoftherotorontothe
ttedendinthehousingandrotatingtherotoruntilitsnaps
intoplace(Figure17).
g013465
Figure17
1.Fittedendoftherotor
Note:Ensurethatthenutthatsecurestherotorpin
remainsinsidetherecessedholeintherightinsidewallof
thehousing.
Note:Thehousingwillexwhenyouinstalltherotor.
5.Tightentheboltonthesideofthehousing.
6.Installtherightsideplatewiththescrewsthatyouremoved
instep1.
9
