g217075

Figure87

1.Brakecable2.Jamnut

4.Pushthebrakepedaldownandmovethebrake

cablesforwardorrearward.

5.Tightenthejamnutstolockthecablepositions.

6.Repeatsteps3through5untilyousetthebrake

pedaltothedesiredposition.

BeltMaintenance

CheckingtheConditionof

theAlternatorBelt

ServiceInterval:Every200hours

Checkalternatorbeltforwearordamage.

Note:Replacethealternatorbeltifyounditworn

ordamaged.

TensioningtheAlternator

Belt

ServiceInterval:Aftertherst10hours

Every200hours

1.Parkthemachineonalevelsurface.

2.DisengagethePTO,lowerthemowerdeck,and

engagetheparkingbrake.

3.Shutofftheengineandremovethekey.

4.Accesstheenginefromtheleftside;referto

AccessingtheEnginefromtheLeftSide(page

49).

5.Loosenthealternatorpivotboltandlockbolt

(Figure88).

6.Tensionthealternatorbeltuntilyouachieve10

mm(3/8inch)beltdeectionmidwaybetween

thepulleyswithaforceof4.5kg(10lb).

7.Tightenthealternatorlockbolt(Figure88).

8.Tightenthealternatorpivotbolt(Figure88).

g216341

Figure88

1.Alternatorlockbolt3.Alternatorpivotbolt

2.Alternator4.Alternatorbelt
