6.Attachthefrontsupportrodtothemowerdeckwith
theclevispinandhairpincotter(Figure54).
7.Installthemowerbeltontotheenginepulley;refer
toReplacingtheMowerBelt.
ReplacingtheGrassDeector
ServiceInterval:Beforeeachuseordaily—Inspectthe
grassdeectorfordamage
WARNING
Anuncovereddischargeopeningcouldallowthe
lawnmowertothrowobjectsintheoperator'sor
bystander'sdirectionandresultinseriousinjury.
Also,contactwiththebladecouldoccur.
Neveroperatethemachinewithoutgrassdeector,
dischargecoverorgrasscollectionsysteminplace.
32inchDecks
1.LocateitemsshowninFigure57.
G014636
1
2
3
4
5
6
7
Figure57
1.Mowerdeck
5.Spring
2.Grassdeector6.Nut(3/8inch)
3.Grassdeectorbracket7.Shortstand-off
4.Rod
2.Removethenut(3/8inch)fromtherodunderthe
mower(
Figure57).
3.Slidetherodoutoftheshortstand-off,spring,and
grassdeector(Figure57).Removethedamaged
orworngrassdeector.
4.Replacethegrassdeector(
Figure57).
5.Sliderod,straightend,throughthereargrass
deectorbracket.
6.Placethespringontherod,withendwiresdown,
andbetweenthegrassdeectorbrackets.Sliderod
throughsecondgrassdeectorbracket(
Figure57).
7.Insertrodatfrontofgrassdeectorintoshort
stand-offondeck.Securerearendofrodintothe
mowerwithanut(3/8inch)(
Figure57).
Important:Thegrassdeectormustbespring
loadedinthedownposition.Liftthedeector
uptotestthatitsnapstothefulldownposition.
42inchDecks
Inspectthegrassdeectorfordamagebeforeeachuse.
Replaceanydamagedpartsbeforeuse.
1.Locateitemsshownin
Figure58.
G005303
1
2
3
4
5
6
7
Figure58
1.Mowerdeck
5.Spring
2.Grassdeector6.Nut(3/8inch)
3.Grassdeectorbracket7.Shortstand-off
4.Rod
2.Removethenut(3/8inch)fromtherodunderthe
mower(
Figure58).
3.Slidetherodoutoftheshortstand-off,spring,and
grassdeector(
Figure58).Removethedamaged
orworngrassdeector.
4.Replacethegrassdeector(
Figure58).
5.Sliderod,straightend,throughthereargrass
deectorbracket.
6.Placethespringontherod,withendwiresdown,
andbetweenthegrassdeectorbrackets.Sliderod
throughsecondgrassdeectorbracket(
Figure58).
7.Insertrodatfrontofgrassdeectorintoshort
stand-offondeck.Securerearendofrodintothe
mowerwithanut(3/8inch)(
Figure58).
39
