StartingtheEngine
Important:Donotengagethestarterformorethan
5secondsatatime.Engagingthestartermotorfor
morethan5secondscandamagethestartermotor.If
theenginefailstostart,wait10secondsbeforeoperating
theenginestarteragain.
Sitdownontheseatandensuretheparkingbrakeisset
(Figure10).
g027831
B
C
D
E
A
F
Figure10
OperatingtheParkingBrake
(SmartPark
™
)
Theparkingbrakeisactivatedelectronically.
Engagetheparkingbrakebyoneofthefollowingactions:
•PressingtheSmartPark
™
switchtotheOnposition
(Figure5).
•Theparkingbrakeengagesautomaticallywhenthe
operatorleavestheseatandthetractioncontrolpedalis
intheneutralposition.
•Theparkingbrakeautomaticallyengages5to6seconds
aftertheignitionswitchisturnedtotheOffposition(if
notalreadyengaged).
Disengagetheparkingbrakebyoneofthefollowingactions:
•Tapthetraction-controlpedalforwardorreverse.
•PressingthebrakeswitchtotheOffposition(Figure5).
OperatingtheBlades
Thebladecontrolswitch,representedbyapowertake-off
(PTO)symbol,engagesanddisengagespowertothemower
blades.Thisswitchcontrolspowertoanyattachmentsthat
drawpowerfromtheengine,includingthemowerdeckand
cuttingblades.
EngagingtheBlades
Important:Donotengagethebladeswhenparkedin
tallgrass.Beltorclutchdamagecanoccur.
Note:Alwaysengagethebladeswiththethrottleinthe
Fastposition.
g027902
Figure11
DisengagingtheBlades
1
g027538
Figure12
1.Powertake-off(PTO)switch
21
