Adjusting the Height of Cut
You can adjust the height of cut from 38 to 127 mm (1-1/2 to 5 inches) in 6.4 mm (1/4 inch)
increments.
G455680
1. Push the deck-lift pedal with your foot to
raise the mower deck.
2. Remove the pin
from the height-of-cut
bracket.
3. Insert the pin into the hole corresponding to
the desired height of cut
.
4. Lower the deck slowly until the lever contacts
the pin.
Using the Transport Lock
G456097
1. Push the deck-lift pedal fully forward to lock
the mower deck in the T
RANSPORT position.
2. Push the deck-lift pedal fully forward and push
the transport lock lever
forward to the
U
NLOCK position, then slowly lower the mower
deck to the desired height of cut.
3464-634A Page 4–15 Operation: During Operation
