skirt;1oneachsideofthecuttingdeck(Figure
74).
10.Settheheight-of-cutlevertothe3inch(76mm)
position.
11.Place2blocksundereachsideofthefrontedge
ofthedeck,butnotundertheanti-scalproller
bracketsorwelds.
g038090
Figure74
Bottomview
1.Block—7.3cm(2.87
inches)
2.Welds
BlockHeightandRakeTable
Deck
Size
FrontBlockHeightRake
Allmower
decks
7.3cm(2.87inches)4.8to6.4mm(3/16to1/4
inch)
12.Carefullyrotatethebladessidetoside(Figure
72).
13.Loosenthelocknuts(Figure75)onall4corners
andensurethatthemowerdeckissitting
securelyonall4blocks.
14.Removeanyslackfromthedeckhangersand
makesurethedeck-liftfootleverispushedback
againstthestop.
15.Tightenthe4locknuts.
g035851
Figure75
1.Locknuts3.Deckhanger
2.Deckliftarm4.Chain
16.Ensurethattheblockstsnuglyunderthedeck
skirtandthatallattachmentboltsaretight
17.Continuelevelingthedeckbycheckingthe
front-to-rearbladeslope.
18.Checkthebladesforlevelnessandrepeatdeck
levelingprocedureifnecessary.
55
