FuelSystem
Maintenance
DrainingtheFuelTank
Incertainconditions,gasolineisextremely
ammableandhighlyexplosive.Areor
explosionfromgasolinecanburnyouand
othersandcandamageproperty.
•Draingasolinefromthefueltankwhenthe
engineiscold.Dothisoutdoorsinanopen
area.Wipeupanygasolinethatspills.
•Neversmokewhendraininggasoline,and
stayawayfromanopenameorwherea
sparkmayignitethegasolinefumes.
1.Parkthemachineonalevelsurface,toensurethat
thefueltankdrainscompletely.
2.Lowertheboomandsettheparkingbrake.
3.Stoptheengine,removethekey,andwaitforall
movingpartstostopbeforeleavingtheoperating
position.
4.Turnthefuelshut-offvalvetotheclosedposition
(Figure40).
Figure40
1.Fuelshut-offvalve
5.Squeezetheendsofthehoseclampontheengine
sideoftheshut-offvalvetogetherandslideitupthe
fuellineawayfromvalve(Figure40).
6.Pullthefuellineoffthevalve(Figure40).Openthe
fuelshut-offvalveandallowthegasolinetodrain
intoagascanordrainpan.
Note:Nowisthebesttimetoinstallanewfuellter
becausethefueltankisempty.RefertoReplacing
theFuelFilter.
7.Installthefuellineontothefuelshut-offvalve.Slide
thehoseclampclosetothevalvetosecurethefuel
line.
8.Wipeupanyspilledfuel.
ReplacingtheFuelFilter
ServiceInterval:Every200hours
Neverinstalladirtylterifitisremovedfromthefuel
line.
Note:Notehowthefuellterisinstalledinorderto
installthenewltercorrectly.
Note:Wipeupanyspilledfuel.
1.Lowertheboomandsettheparkingbrake.
2.Stoptheengine,removethekey,andwaitforall
movingpartstostopbeforeleavingtheoperating
position.
3.Turnthefuelshut-offvalvetotheclosedposition
(Figure40).
4.Squeezetheendsofthehoseclampstogetherand
slidethemawayfromthelter(Figure41).
Figure41
1.Hoseclamp3.Filter
2.Fuelline
5.Removethelterfromthefuellines.
6.Installanewlterandmovethehoseclampsclose
tothelter.
7.Turnthefuelshut-offvalvetotheopenposition
(Figure40).
8.Checkforfuelleaksandrepairifneeded.
9.Wipeupanyspilledfuel.
30
