Toro TWRS-I User Manual

4
Receiver Module Features
1– Setup Button–Accesses the receiver setup and operating
features.
2– Adjust Button–Selects settings within the receiver setup
and operating features.
3– Mast Antenna–Adjusts easily for best signal reception.
4– Digital Display–High-resolution LCD screen provides visual
reference for sensor system operating features.
5– Sensor Status Indicators– Rain status and Freeze status
(TWRFS-I only) indicators illuminate when the sensor
system is active and automatic watering is on hold.
6– Smart Bypass
TM
Button–Multi-functional use. Pressed
to bypass sensor operation, allowing automatic watering to
resume. Switches the Water Delay feature on and off.
7– Water Conservation LEDs–Indicate the Water
Conservation feature level selected (Minimum, Medium or Maximum).
8– Hinged Cover–Opens downward for receiver control access.
Closed position protects receiver when installed outdoors.
3
4
5
6
7
8
1
2
373-0372a_E/S/F 6/7/05 1:59 PM Page 4
