InstallingtheAir-Cleaner
Cap
InternationalMachinesUsing
GasolineOnly
Partsneededforthisprocedure:
1Air-cleanercap
1Hoseclamp
Procedure
Note:Notallthemachinescomewithaheavyduty
aircleaner.Thisprocedureappliesonlytothemodels
thathaveaheavydutyaircleaner.
1.Removetheplasticplugortapecoveringthe
aircleaner.
g001658
Figure20
2.Installthehoseclampontotheair-cleanercap.
g001659
Figure21
3.Installtheair-cleanercapontotheaircleaner
andsecureitwiththehoseclamp.
g001660
Figure22
10
