Toro Z Master 4000 Series Setup Instructions

15
InstallingtheROPS
InternationalMachinesUsing
GasolineOnly
Partsneededforthisprocedure:
1
RolloverProtectionSystem(ROPS)Kit
Procedure
InstalltheRolloverProtectionSystem(ROPS)Kit.
FollowtheInstallationInstructions.
16
InstallingtheROPS
DieselMachinesOnly
Partsneededforthisprocedure:
1Rollbar,rightsection
1
Rollbar,leftsection
1Rollbar,centersection
8
Bolt(3/8x1inch)
8
Curvedwasher
8
Flangenut(3/8inch)
2
Bolt(1/2x3-1/4inches)
2
Flangenut(1/2inch)
Procedure
1.Looselyinstalltherightandleftrollbarsection
totheframeusingthe8bolts(3/8x1inch),8
curvedwashers,and8angenuts(3/8inch).
Note:Installthecurvedwasherconetoward
thebolthead.
g001077
Figure23
2.Installthelanyardclipsontothelongbolts(1/2x
3-1/4inches).
Note:Ensurethatthebenttabpointstoward
theheadofthebolt.
g001072
Figure24
3.Lightlyoiltheendsofthecenterrollbarsection.
4.Looselyinstallthecenterrollbarsectionusing
2bolts(1/2x3-1/4inches)and2angenuts
(1/2inch).
Note:Installtheboltsfromtheoutsideofthe
rollbar.
Note:Installthelanyardtaborientedasshown
inFigure25andpointingforward.
