AdjustingtheHeight-of-CutPin
Mowerdecksize
Height-of-cutrange
Increments
48inch
1-1/2to5inches
(38to127mm)
1/4inch(6mm)
52inchand60inch
1-1/2to5-1/2
inches(38to140
mm)
1/4inch(6mm)
Theheight-of-cutisadjustedbyrelocatingtheclevis
pinintodifferentholelocations.
1.Movethetransportlocktothelockposition.
2.Pushonthedeckliftpedalwithyourfootandraise
themowerdecktothetransportposition(also
the5-1/2inch(140mm)cuttingheightposition)
(
Figure25).
3.Toadjust,rotatethepin90degreesandremovethe
pinfromtheheight-of-cutbracket(Figure25).
4.Selectaholeintheheight-of-cutbracket
correspondingtotheheight-of-cutdesiredand,
insertthepin(
Figure25).
5.Pushonthedecklift,pullbackonthetransport
lock,andslowlylowerthemowerdeck.
g017419
2
1
3
Figure25
1.Deckliftpedal
3.Transportlock
2.Cutofheightpin
AdjustingtheAnti-Scalp
Rollers
Wheneveryouchangetheheight-of-cut,itis
recommendedtoadjusttheheightoftheanti-scalp
rollers.
1.Disengagethebladecontrolswitch(PTO),move
themotioncontrolleverstotheneutrallocked
positionandsettheparkingbrake.
2.Stoptheengine,removethekey,andwaitforall
movingpartstostopbeforeleavingtheoperating
position.
g017628
Figure26
1.Anti-scalproller4.FlangeNut
2.Spacer
5.Bolt
3.Bushing
g017629
Figure27
1.Anti-scalproller3.FlangeNut
2.Bushing4.Bolt
PositioningtheSeat
Theseatcanmoveforwardandbackward.Positionthe
seatwhereyouhavethebestcontrolofthemachine
andaremostcomfortable.
Toadjust,movetheleversidewaystounlockseat
(Figure28).
